Quik Latch

QL-38 Series Lockable Hood Pin Kits

QL-38 Series Lockable Hood Pin Kits

Regular price $241.49 USD
Regular price Sale price $241.49 USD
Sale Sold out
Shipping calculated at checkout.
Color

RaiderFab is a proud distributor for Quik-Latch, the original American made latches NHRA Certified and proven to stand up to the elements!

Designed with the import performance market in mind, the QL-38 series hood pin kits deliver the same push button function that you've come to expect from Quik-Latch Products while retaining serious holding ability that is required of hood pins.  The reduced Physical presence of the 38 series hood pin kits ensures a clean and unassuming look that will blend in with your overall build.

You've spent thousands upgrading your car's mechanicals, electrical, body and paint.  Why install a hood pin made of substandard materials that could rust after just a few years?  Go with Quik-Latch hood pins and make the finishing touch to your project car representative of the pride you have in your ride!

***All latch orders now come with complimentary threadlocker at no additional cost!***

Also available in machined by special order.

Specs:
Materials: 6061 T6 Aluminum / 303 Stainless Steel
Holding Force: 500lbs per latch
Weight: 4.7 ounces
Height: 1.50 inch (38 mm)
Height Below Mounting Flange: 1.375 inch (35 mm)
OD of the latch mounting flange: 1.75 inch (44.5mm)
Thread size of latch body: 1 1/8 x 24 UNEF
Hole size required to mount latch: 1.25 inch (32mm)
Pin dimensions: 3/8" ball with 3/8 x 24 thread
Retaining Ring: 1.50 inch (38mm) OD x .25 inch (6.4) thickness
Minimum distance from top of mounting surface to mounting point: 1.125 inch (28.50 mm)
Maximum distance from top of mounting surface to mounting point: 3.50 inch (88 mm)
Maximum mounting angle: 18 degrees
Distance needed to engage pin into latch: .687 inch (17.5mm)
